Gear-driven sprinkler PGP-12 Ultra - HUNTER

The PGP Ultra gearbox sprinkler offers versatile options for every location. Based on customer feedback, laboratory testing and research, HUNTER's best-selling geared sprinkler, the PGP, has been further developed. The most notable improvements to the PGP Ultra are a decoupling mechanism that protects the sprinkler gearbox from vandalism and automatic sector return. Both functions allow the sprinkler head to be manually rotated in any direction, with the sprinkler then automatically returning to its original sector.
A total of 22 nozzle options offer a wide range of radius selection options.

To make installing the nozzles easier and more convenient, we recommend using the adjustment key and the Halteklammer für den Aufsteiger zu verwenden.

Further information on the PGP Ultra gearbox sprinklers and the performance data can be found here.

Dimensions

• Width: 430 mm
• Height: 79 mm
• Depth: 79 mm

Specifications

• Total height: 43 cm
• Rising height: 30 cm
• Exposed diameter: 4.5 cm
• Sector adjustment: 50 to 360 degrees
• Factory-fitted rubber protective cover
• Sector adjustment through the upper part
• Fast sector locking mechanism
• Water-lubricated gearbox
• Available nozzles: 22
• Nozzle set, enclosed: 1.5 to 8.0 (standard) blue; 2.0 to 4.0 LA (flat jet) gray
• Düsensets, can be ordered separately: 0.50 to 3.0 (short radius) black; 6.0 to 13.0 (high flow) grün; Matched Precipitation Düsensets MPR-20, MPR-30, MPR-35
• Regner connection: ¾" BSP female thread (ø 24.12 mm)
