Hunter NODE-BT-100-LS Bluetooth control unit, 1 station, battery-powered

HUNTER NODE- BT 100-LS Bluetooth app control with 1 station

The perfect choice when no AC power supply is available!

The waterproof NODE-BT control unit (IP68 certified) features powerful Bluetooth technology, allowing convenient control from a smartphone.
The app displays the control units by location and sends reminders to change the batteries. The control unit can be equipped with a Mini-Clik sensor, Rain-Clik sensor and the SC-Probe soil moisture sensor.

ATTENTION: The NODE-BT control unit does not work with standard 24 V AC coils, but requires valves equipped with 9 V pulse coils.
This model does not include a 9V solenoid coil.

Dimensions

• Width: 232 mm
• Height: 160 mm
• Depth: 104 mm

Specifications

• Number of stations: 1
• Irrigation programs: 3
• Start times per program: 8
• Station run time: between 1 second and 12 hours
• Irrigation interruption up to 99 days
• Seasonal adjustment (monthly and global) enables faster schedule adjustments
• Can be attached to HUNTER impulse coils or pipes in the valve box or flat surface
• Warranty period: 2 years
• 9 V alkaline batteries: 1 or 2
• Suitable only for DC impulse coils (P/N458200)
• Sensor inputs: 2
• Station output: 9-11 VDC - P/MV
• Output: 9-11 VDC
• 30 m maximum cable length with 1 mm² wire cross-section
• Magnetic coil not included in delivery

APP Specifications

• iOS 9.0 or higher
• Android 5.0 or higher
• Maximum communication range: approx. 15 m
